Systematic Review Example

Updated November 11, 2026 12 min read About 2,300 words
Text size

This systematic review example walks through a complete, small review from the question to the results text. The data are invented for teaching, so do not cite them, but the steps, numbers and wording show how a real review fits together.

You will see the question and PICOS, the protocol, the search, the flow numbers, a risk of bias summary, the extraction table, a pooled estimate with equations and a short results and discussion text.

  • The plan: question, protocol and search.
  • The selection: flow numbers, appraisal and extraction.
  • The results: pooled estimate, text and discussion.

Key takeaways

  • The example asks whether bedside handover reduces medication errors on adult wards.
  • The search found 2,640 records; 12 studies were included and 3 are pooled in the worked calculation.
  • The pooled risk ratio is 0.73 (95% CI 0.59 to 0.90) in the illustration.
  • All numbers are illustrative and should not be cited as real evidence.

The example at a glance

The table summarises the review before the detail. Everything here is illustrative.

Item Entry
Title Bedside handover and medication errors on adult wards: a systematic review (illustrative)
Question Does bedside nursing handover reduce medication errors compared with desk handover?
Databases MEDLINE, CINAHL and Embase, searched on 3 March 2026
Records identified 2,640
Studies included 12 (3 used in the worked pooled calculation)
Main result Pooled risk ratio 0.73, 95% CI 0.59 to 0.90

For the method behind it, see the systematic literature review guide.

Step 1: the question and PICOS

The review question was framed with PICO and a design element (PICOS).

Element Entry
Population Nurses and patients on adult inpatient wards
Intervention Structured bedside handover
Comparison Desk or verbal handover without the patient
Outcome Medication errors per 1,000 patient days
Study design Randomised and controlled before-and-after studies

The framework is explained in the PICO framework guide.

The PICOS framework for the systematic review example: population, intervention, comparison, outcome and study design
The PICOS elements of the systematic review example.

Step 2: the protocol

The protocol was written before the search.

  • Registration: registered on PROSPERO (illustrative number).
  • Criteria: adult wards, English, 2010 to 2025, error rate reported.
  • Selection: two reviewers; conflicts resolved by a third.
  • Appraisal: Cochrane RoB 2 for trials and ROBINS-I for other designs.
  • Synthesis: random-effects meta-analysis of risk ratios if at least three comparable studies.

The search combined three concepts. See the literature search strategy and Boolean operators guides.

Line Search (MEDLINE, Ovid style) Records
1 (“bedside handover” or “bedside report*” or “nursing handover”).ti,ab. 1,480
2 (medication error* or “drug error*” or “patient safety”).ti,ab. 61,300
3 1 and 2 212
4 Subject headings: exp Patient Handoff/ and exp Medication Errors/ 190
5 3 or 4 (final set for this database) 350
  • Other sources: CINAHL and Embase were searched with equivalent strings; reference lists were checked.
  • Total: 2,640 records across all sources before deduplication (illustrative).

Step 4: study selection and the flow numbers

The numbers follow the PRISMA 2020 flow diagram. See the PRISMA flow diagram guide.

Stage Records
Identified from databases and registers 2,640
Duplicates removed 610
Screened on title and abstract 2,030
Excluded on title and abstract 1,870
Full texts assessed 160
Excluded at full text (wrong design 70, wrong setting 48, no error data 30) 148
Studies included 12
Illustrative systematic review example funnel with record counts: 2,640 identified, 2,030 screened, 160 assessed, 12 included and 9 in the meta-analysis
The flow of a systematic review example in numbers.

Step 5: risk of bias

Each study was judged by two reviewers.

Judgement Studies
Low risk 5
Some concerns 5
High risk 2
  • Common concerns: lack of blinding of outcome assessors and incomplete follow-up.
  • Sensitivity analysis: the pooled result was checked without high-risk studies.
  • Report: a traffic-light figure and a table of judgements.

Step 6: data extraction

The form recorded design, setting, sample, intervention and results. Three studies reporting risk ratios are shown.

Study Design Wards Risk ratio SE of ln(RR)
A (2018) Randomised 6 0.70 0.20
B (2020) Controlled before and after 4 0.80 0.15
C (2022) Randomised 8 0.60 0.25

Step 7: pooling the results

Risk ratios are pooled on the log scale with inverse-variance weights.

  • Interpretation: bedside handover was associated with about a 27% lower rate of medication errors.
  • Caution: three studies are few; the review should not claim more than moderate certainty.
  • Learn more: see what is meta-analysis.

Writing the results

A short results paragraph from the example shows the style.

Writing the discussion

The discussion interprets the result and states limits.

  • Summary: bedside handover probably reduces medication errors.
  • Comparison: state how the finding compares with earlier reviews.
  • Limits: few studies, short follow-up, differences in how errors were counted.
  • Implications: wards could pilot bedside handover with audit of errors.
  • Research: larger trials with night shifts and longer follow-up.

How to use this systematic review example

Use it as a model, not a source.

What the example teaches

Several lessons come out of the walkthrough.

  • Plan first: the protocol set the criteria before any searching.
  • Count carefully: every number in the flow diagram was reconciled.
  • Report reasons: full-text exclusions had stated reasons.
  • Pool only comparable studies: three of 12 studies could be pooled.
  • Be cautious: the conclusion stressed moderate certainty.

Summary of findings table (illustrative)

A summary of findings table gives the main result and its certainty in one place.

Outcome Studies Result Certainty Reason
Medication errors 3 trials RR 0.73 (0.59 to 0.90) Moderate Some risk of bias
Handover time 5 studies Longer by 4 minutes per shift Low Inconsistency
Patient satisfaction 4 studies Higher with bedside handover Low Imprecision and risk of bias
  • Plain language: state the finding in a sentence.
  • Downgrade: explain why certainty was lowered.

Reading the flow numbers

Each step in the flow diagram answers a question.

Step Question answered
Identification How many records did we find?
Duplicates removed How many were repeats?
Screening How many were clearly irrelevant?
Full texts How many met the criteria after reading?
Included How many studies does the review use?

Limits of the example review

Every review has limits. The example would state these.

  • Few pooled studies: only three could be combined.
  • Differences in error counting: studies defined errors differently.
  • Short follow-up: most studies lasted under six months.
  • Setting: all studies were in high-income countries.
  • Publication bias: not testable with so few studies.

Adapting the example to your own topic

Use these steps to adapt the example.

  • Change the PICOS: for your question.
  • Rewrite the criteria: to fit your design and dates.
  • Redo the search: with your concepts.
  • Choose appraisal tools: suited to your designs.
  • Decide the synthesis: narrative or meta-analysis.

For a deeper method, see what is a systematic literature review.

Extra detail: sensitivity analysis

A sensitivity analysis checks whether the result depends on certain decisions.

  • Remove high-risk studies: the pooled risk ratio stayed close to 0.73.
  • Change the model: a random-effects model gave the same estimate because heterogeneity was zero.
  • Leave one out: removing each study in turn changed the result only slightly.
  • Report: state what changed and what stayed the same.

Reading a forest plot for the example

A forest plot shows each study and the pooled result.

  • Squares: show each study’s risk ratio; larger squares mean greater weight.
  • Lines: show 95% confidence intervals.
  • Diamond: shows the pooled estimate and its interval.
  • Vertical line: at 1 marks no effect.
  • In the example: all three squares sit left of 1, and the diamond (0.59 to 0.90) does not cross 1.

A reporting checklist for your own review

Use this list when you write your own review.

  • Title: identifies the review type.
  • Protocol: registered and cited.
  • Search: strings and dates in an appendix.
  • Flow diagram: with balanced numbers.
  • Risk of bias: reported for every study.
  • Certainty: rated for each outcome.

Where to find real systematic review examples

A real systematic review example is more useful than any invented one. Browse the Cochrane Library, open-access journals and your own database. Read each systematic review example with the PRISMA checklist beside you.

  • Pick one on your topic: a recent, well-cited review.
  • Mark the sections: methods, results and discussion.
  • Compare: with this systematic review example to see what is similar.
  • Learn the language: note how authors report numbers and limits.

Another systematic review example: a qualitative synthesis outline

Not every systematic review example pools numbers. This one synthesises qualitative studies.

Item Entry (illustrative)
Question How do patients experience discharge from intensive care?
Framework SPIDER
Search CINAHL, MEDLINE, PsycINFO; 1,210 records
Included 14 qualitative studies
Appraisal CASP checklist; all rated moderate or high quality
Synthesis Thematic synthesis with three themes: feeling unprepared, relying on family, regaining control
Confidence CERQual: moderate for two themes, low for one
  • Difference: this systematic review example uses themes, not pooled numbers.
  • Tools: see SPIDER framework for the question format.

Comparing the two systematic review example types

Each systematic review example fits a different question.

Feature Quantitative example Qualitative example
Question Does X reduce Y? How do people experience X?
Studies Trials and cohorts Interviews and focus groups
Appraisal RoB 2 or ROBINS-I CASP
Synthesis Meta-analysis Thematic synthesis
Certainty GRADE GRADE-CERQual

How long would this systematic review example take?

Even a small systematic review example takes time. For the example above, a team of two could expect the following.

Stage Time (illustrative)
Protocol and registration 3 weeks
Searching and deduplication 2 weeks
Screening 2,030 records 4 weeks
Full texts, extraction and appraisal 6 weeks
Synthesis and writing 6 weeks
  • Total: about five months for a focused review.
  • Larger reviews: take a year or more.
  • Tip: screening tools and a clear protocol shorten each stage.

Frequently asked questions about systematic review example

Can I use this systematic review example as a source?

No. The question, numbers and results in this walkthrough are invented to show how the parts of a systematic review fit together, so they are not real evidence and should not be cited. You can use the structure, the wording of the sections and the calculations as models for your own review, replacing the question, criteria, search and results with your own. If you want real examples, look in the Cochrane Library, journals that publish systematic reviews or your own subject databases, and read them with a reporting checklist such as PRISMA beside you.

How many studies does a systematic review example need?

A systematic review can include any number of studies, from a handful to hundreds. This example included 12 studies, which is typical for a focused student review, and used three for the worked calculation to keep the arithmetic simple. What matters is that the search was comprehensive, the criteria were applied consistently and the number of included studies is reported honestly. If few studies exist, report that clearly and discuss what it means for the evidence and for future research.

Why did the example pool only three studies?

Meta-analysis requires studies that are similar enough in population, intervention, comparison and outcome, and that report data in a compatible form. In the example, only three of the 12 studies reported risk ratios for the same outcome, so only they could be pooled. The other studies were summarised narratively. In real reviews, authors decide in the protocol how they will choose studies to pool and report why some were left out, which reduces the risk of selecting studies to fit a desired result.

What does I-squared of zero mean in the example?

An I-squared of zero means that the observed differences between the three studies were no greater than expected by chance, so there is no evidence of heterogeneity. This is common when only a few studies are pooled, because the tests have low power and cannot detect small differences. It does not prove that the studies are identical, and the estimate should still be interpreted with care. In a real review you would also look at differences in design, setting and risk of bias, and report a prediction interval if a random-effects model is used.
